「快速门电控箱」堆积门变频控制箱的技术特点

「快速门电控箱」堆积门变频控制箱的技术特点


The Technical Characteristics of "Fast Gate Electronic Control Box" Stacking Gate Frequency Converter Control Box


变频柜，普通的动力柜或控制柜由传统拖动方式改为变频拖动方式。简而言之：应用变频器拖动动力装置的控制柜。


Frequency conversion cabinet, ordinary power cabinet or control cabinet is changed from traditional drive mode to frequency conversion drive mode. In short: the application of frequency converter to drive the control cabinet of power plant.


因其良好的启动性能、调速性能和节能效果而成为当前推广的动力拖动方式。


Because of its good start-up performance, speed regulation performance and energy-saving effect, it has become the current promotion of power drive mode.

「快速门电控箱」性能稳定可靠，抗干扰性好：PLC应用于各种工业控制现场，其硬件及软件设计均考虑到各种生产环境，其电压适用范围很宽，具有极强的抗电磁干扰、抗震动、抗高温、高湿等特性，性能极为稳定、可靠。


"Fast Gate Electronic Control Box" has stable and reliable performance and good anti-interference: PLC is used in various industrial control sites, its hardware and software design takes into account various production environments, its voltage range is wide, with strong anti-electromagnetic interference, anti-vibration, high temperature, high humidity and other characteristics, the performance is extremely stable and reliable.


PLC自动化控制系统应用在冷冻干燥机上可以完成智能控制、状态显示和故障报警等任务，同时还提供良好的人机界面与操作员进行交互，使得修改各种参数简单、易行，对于机械设备的运行能及时、快速、准确的反映


The application of PLC automation control system in freeze dryer can accomplish the tasks of intelligent control, status display and fault alarm. It also provides a good man-machine interface to interact with operators, which makes the modification of various parameters simple and easy, and reflects the operation performance of mechanical equipment in a timely, fast and accurate manner.



「快速门电控箱」堆积门变频控制箱的技术特点


The Technical Characteristics of "Fast Gate Electronic Control Box" Stacking Gate Frequency Converter Control Box


一、技术特点


I. Technical Characteristics


1、高度的集成功能


1. High Integration Function


把所有的功能集成化，减少了传统门机使用的变频器+PLC的控制方式，只使用变频器可以满足所有的功能。


The integration of all functions reduces the control mode of frequency converter + PLC used in traditional portal crane, and only using frequency converter can satisfy all functions.



2、节能成本


2. Energy-saving Cost


减少PLC及相关配件，使控制箱的体积减小，节约成本。


Reduce PLC and related accessories, reduce the volume of the control box, save costs


3、简化门机控制系统，提高系统安全性。


3. Simplify the door crane control system and improve the system security.


省去了传统快速门机控制系统中PLC控制的中间环节，提高系统安全性。


The intermediate link of PLC control in the traditional fast door crane control system is omitted and the system security is improved.


4、高性能控制


4. High Performance Control


起动力矩大、运行平稳、高效。


Large starting moment, smooth operation and high efficiency.


实时检测输出力矩，受阻力矩可灵活设置。


The output torque can be detected in real time, and the resistance moment can be flexibly set.


零速保持力矩输出，保证开关门到位的保持力矩。


Zero speed to maintain the torque output, to ensure that the switch door in place to maintain the torque.


5、控制方式


5. Control Mode


支持地磁控制、雷达控制、光电、气囊等设置


Support geomagnetic control, radar control, optoelectronic, airbag and other settings


6、输入输出端子


6. Input and output terminals


专用化的门机输入输出端子设计，接线方便


Specialized portal crane input and output terminal design, easy wiring

二、变频器性能说明


2. Performance description of frequency converter


1、CPU采用美国TI公司的32位级DSP控制器，使性能更完美；


1. CPU adopts 32-bit DSP controller of TI Company of America, which makes the performance more perfect.


2、IGBT使用美国仙童公司生产的模块，保证产品更高效；


2. IGBT uses modules produced by American Fairchild Company to ensure more efficient products.


3、电容采用日本尼吉康的产品，保证产品的使用寿命更久；


3. Capacitors adopt Nijikang's products to ensure longer service life.


4、其它主要器件全部用进口器件，保证产品的性能更稳定；


4. All other major devices are imported devices to ensure more stable performance of products.


5、SMT表贴工艺，结构紧凑，可靠性强；


5. SMT surface mounting technology, compact structure, strong reliability;


6、按键操作，中文液晶显示，人机界面友好、可操作性强；


6. Keyboard operation, Chinese LCD display, friendly man-machine interface, strong operability;

订购「快速门电控箱」欢迎联系我们的客服人员，我们提供全国配送上门，免费指导安装服务。


Ordering "Fast Gate Electronic Control Box" welcome to contact our customer service personnel, we provide nationwide distribution door-to-door, free guidance and installation services.
